Keep the main thing... the main thing

• Clean, neutral input channel, preserving the character of the source


• Balanced internal circuitry at +4 dBu, tons of headroom, excellent interference cancellation and low noise

• Localized summing for signal integrity and low noise

More options than a Ginsu knife!

• 3 simultaneous, summable inputs

• 3 stereo Mix buses

• 8 Sends (2 Mono and 1 Stereo with 3 assignable busses)

• Insert point with a blend

• "Inline" design that splits input channel into two independent paths

• All key points in the signal path available via DB25s.

• Expansion bus and send modules (808, 508)

The Polymath

• DAW (Digital Audio Workstation) mode, similar to traditional inline console designs


• In DAW mode, large fader controls level from DAW and small fader/pot controls tracking level

• Seamless transition between tracking and mixing phases

• In Mix or "Summing mode", each channel supports 4 inputs. A 24 channel console supports 96 inputs on mix down!

Here's the beef! In every classic flavor.

• 3 slots - mix and/or match tones

• Signal path includes multiple stages of amplification and transformer coupling

• Available options: Capi Red Dot, Tonelux, 990s, Melcore, Nickel, and custom!

• Insert point with blend for bus compression or other processing

• +4 dBu operating level for optimal headroom and low noise

• More tones with 808M Module

Infinite expansion and processing options from "Mr 500"

• Integrated 500 series slots for additional processing modules

• Insert Wolff 500 modules or 3rd party - preamps, EQs, compressors, etc

• 500 buckets can be positioned anywhere within a custom console layout (including remotely in a rack)

• All I/O from 500 series buckets is available on DB25s to route internally or to external patchbay

Best of both worlds

• Analog or Digital metering - user's choice, mix and match

• Classic analog meters with great ballistics

• Digital meters have incredible responsiveness, and can display a bazillion different things (Designed with THD Labs)

• Monitor input levels, bus levels, or output levels - signal path insert points are available for additional options

• Grand Master meters automatically follow the selected monitoring source

True "flying faders" for fully analog mix automation

• 100mm analog fader and mute automation for level control (Designed with THD Labs)

• Relative and absolute modes, and solo-in-place

• Faders can be used as controllers to automate a variety of supported DAWs

Any way you want it, that's the way you'll get it

• Modular "bucket" design allows full customization of channels and processing

• The "sound" of the console is defined by the installed Tone Cards

• Profile/angle fully customizable - classic rake or shallow slope

• Options: Center "Producer Section," Master Section on the side, additional busses in a side rack, and many more

• Bucket modularity allows for easy reconfiguration and expansion as needs change

"If it ain't broke, we don't have to fix it!"

• Reliability designed in to minimize downtime and maintenance

• All switches are relay based to increase longevity and avoid signal issues

• Dual-gang potentiometers wired in parallel for signal redundancy.

• Power supplies are distributed to each bucket for isolation and easy troubleshooting.

"Never be a groove buster"

• We will be there for you!

• 1yr warranty on parts with quick turnaround on repairs

• Spare modules are provided with larger console purchases (or can be purchased)

• Designed for easy "Field" replacement / repair / upgrade

• "In kind" shipping - if shipped to us overnight, we will ship back overnight
